jeniüs ⅲ modulo fotovoltaico monofacciale da 395w-550w
jt seh 108 celle / jt sgh 144 celle

modulo mono prec a 144 celle, con progetto half-cut e tecnologia mbb evoluta, potenza massima di uscita 550w, è perfetto per impianti industriali e commerciali montati a terra e per progetti fotovoltaici residenziali.
module
split module design, 1/4 rs loss; current in half, lower hot spot temperature
cell 91 x 182 mm
mbb mono perc cells, with round solder strip, enhance power generation efficiency
glass 3.2 mm
high strength and transparency coated tempered glass
frame 35 mm
ultra-strong anodized aluminum alloy frame, high mechanical load
junction box ip68
high waterproof and dustproof level, higher security
cable 4.0 mm2
special pv cable with high transmission performance, lower power loss

jt seh 395w-415w

jt sgh 530w-550w

cells：108 [2x(6x9)]

module dimensions：1724 x 1134 x 35 mm

module weight：22.2 kg

cells：144 [2x(6x12)]
module dimensions：2279 x 1134 x 35 mm
module weight：29 kg

note:the specification and key features described in this datasheet may deviate slightly and are not guaranteed. due to ongoing innovation, r&d enhancement, jetion

solar (china) co., ltd. reserves the right to make any adjustment to the information described herein at any time without notice. please always obtain the most

recent version of the datasheet which shall be duly incorporated into the binding contract made by the parties governing all transactions related to the purchase

and sale of the products described herein.
