poly pv module 270w-345w
jt ppg 60 cells / jt pag 72 cells
72 cells standard poly pv module, with mature 5bb tech, maximum power output 345w, is perfect for utility-scale pv projects.
module
mature module desig, optimized bom, highly reliable long-term output performance
celles 157 x 157 mm
5bb high efficiency polycrystalline cells
glass 3.2 mm
high strength and transparency coated tempered glass
frame 35 mm
ultra-strong anodized aluminum alloy frame, high mechanical load
junction box ip68
high waterproof and dustproof level, higher security
cable 4.0 mm2
special pv cable with high transmission performance, lower power loss

jt ppg 270w-285w		jt pag 330w-345w
1		1
cells：60 (6x10) module dimensions：1640 x 992 x 35 mm module weight：18 kg		cells：72 (6x12) module dimensions：1956 x 992 x 35 mm module weight：22 kg

note:the specification and key features described in this datasheet may deviate slightly and are not guaranteed. due to ongoing innovation, r&d enhancement, jetion

solar (china) co., ltd. reserves the right to make any adjustment to the information described herein at any time without notice. please always obtain the most

recent version of the datasheet which shall be duly incorporated into the binding contract made by the parties governing all transactions related to the purchase

and sale of the products described herein.
